Valcourt St-Laurent Linear Decorative Wood Fireplace (FP16D)
The Valcourt St-Laurent FP16D is a wide, linear decorative wood fireplace designed for visual impact and efficient heating. With its guillotine-style glass door, large viewing area, and non-catalytic combustion, it blends elegance and high performance—ideal for spaces under ~1,000 sq ft.
- Non-catalytic combustion with high burn rate (>11 lb/hr)
- Guillotine ceramic glass door with matching screen for safety and ease of loading
- Firebox capacity: 6.4 cu ft; accepts large logs (up to ~30″ width)
- Large ceramic glass viewing surface (~41 1/8″ × 14 7/8″)
- Designed for an 8-inch chimney, with UL & ULC safety standards
Quick Facts
- Recomm. heating area: under 1,000 sq. ft.
- Firebox volume: 6.4 cu ft
- Maximum log length: ~30 inches (east-west loading)
- Overall dim’n (W×H×D): approx 62 5/8″ × 63 3/4″ × 31 3/4″
- Weight: ~765 lb (347 kg)
Technical Specifications
| Brand | Valcourt |
|---|---|
| Model | FP16D (St-Laurent) |
| Type | Decorative linear wood fireplace |
| Fuel | Dry cordwood (16″ recommended) |
Performance
| Heating Capacity | Up to ~1,000 sq ft |
|---|---|
| Burn Rate | > 11 lb/hr (> 5 kg/hr) |
| Combustion Type | Non-catalytic |
| Chimney / Flue Diameter | 8″ (203 mm) |
| Min Chimney Height | 15 ft |
Dimensions & Materials
| Firebox Volume | 6.4 cu ft |
|---|---|
| Glass Type | Ceramic glass |
| View Surface (Glass W×H) | ~41 1/8″ × 14 7/8″ |
| Overall Size (W×H×D) | ~62 5/8″ × 63 3/4″ × 31 3/4″ |
| Weight | ~765 lbs (347 kg) |
FAQs
What room size will this heat?
Designed for rooms up to ~1,000 sq ft, depending on insulation, layout, and climate conditions. :contentReference[oaicite:0]{index=0}
Is the FP16D EPA certified?
This model is exempt from EPA 2020 certification but is built to high efficiency with non-catalytic combustion. :contentReference[oaicite:1]{index=1}
How big of logs can it take?
It accepts large logs loaded east-west, up to ~30 inches. :contentReference[oaicite:2]{index=2}
What kind of door does it have?
Features a guillotine-style ceramic glass door with steel frame and an accompanying safety screen. :contentReference[oaicite:3]{index=3}
What are the flue and chimney requirements?
Requires an 8″ flue outlet, chimney complying with UL 103 HT / CAN/ULC S629, minimum height ~15 ft. :contentReference[oaicite:4]{index=4}
Warranty
Valcourt St-Laurent FP16D — Manufacturer warranty: Limited lifetime on major components, with graded terms for parts & labor. :contentReference[oaicite:5]{index=5}
Coverage
| Component | Term | Notes |
|---|---|---|
| Combustion chamber, castings, ceramic glass | Lifetime | Requires proof & one-time replacement. :contentReference[oaicite:6]{index=6} |
| Stainless steel firebox parts, surrounds, heat shields, trims, baffle, secondary air tubes | 5 years | Parts; labor typically 3 years. :contentReference[oaicite:7]{index=7} |
| Carbon steel firebox parts, glass retainers, handles | 3 years | Parts; labor usually 2 years. :contentReference[oaicite:8]{index=8} |
| Grate, sensors, controls | 2 years | Parts; labor 1 year. :contentReference[oaicite:9]{index=9} |
| Paint, gaskets, insulation, refractory bricks, ceramic fiber | 1 year | Parts only. :contentReference[oaicite:10]{index=10} |
Conditions & Exclusions
- Valid only for the original purchaser; proof of purchase required. :contentReference[oaicite:11]{index=11}
- Warranty void if installed improperly, modified, or misused. :contentReference[oaicite:12]{index=12}
- No coverage for damage from over-firing, venting issues, or lack of maintenance. :contentReference[oaicite:13]{index=13}
- Scratches, cosmetic defects, transport damage not covered. :contentReference[oaicite:14]{index=14}
Manuals & Installation
- Owner & Installation Manual: Download (PDF) :contentReference[oaicite:15]{index=15}
Pre-Installation Checklist
- Ensure hearth base is level and strong enough to support ~765 lb weight. :contentReference[oaicite:16]{index=16}
- Install approved 8″ Class A chimney system. :contentReference[oaicite:17]{index=17}
- Provide fresh air intake in modern, airtight homes. Optional register available. :contentReference[oaicite:18]{index=18}
- Respect all mounting dimensions, clearances, and use high-temperature sealants. :contentReference[oaicite:19]{index=19}
Compliance & Safety
Install per Valcourt’s Installation & Operation Manual and all applicable local building and fire safety codes. Use certified chimney systems and maintain clearances. :contentReference[oaicite:20]{index=20}
Glass door fully closed or, when open, the screen door must be used. Never leave unit unattended when operating. :contentReference[oaicite:21]{index=21}
