Empire Rushmore Insert 30" - DVCT30CBN95N/P
Empire Rushmore 30″ Direct Vent Gas Insert (DVCT30CBN95)
The Rushmore 30 insert blends compact design with high-performance TruFlame® dual-burner flame technology and clean-face styling. With a maximum output around 30,000 BTU (natural gas) and strong emissions control, it turns masonry fireplaces into efficient, sleek gas focal points. It includes remote control, blower, accent lighting, and offers either flame-only or heat modes for flexible ambiance vs. warmth.
- Up to ~30,000 BTU (natural gas) / ~28,500 BTU (propane)
- Flame-only + heat mode with TruFlame dual burners
- Includes blower and accent lighting
- Clean-face design for flush installation to surrounds
- Remote control with thermostat, flame, light, blower functions
Quick Facts
- Fuel: Natural Gas / Propane (select model)
- BTU Range: ~30,000 / ~8,500 (NG) / ~28,500 / ~10,000 (LP)
- Venting: Direct Vent 5″ × 8″ (coaxial)
- Viewing Glass: ~25.5″ W × (height per spec)
- Includes blower, remote, accent light
- Warranty: 10-year combustion / lifetime glass / 3 years parts
Technical Specifications
| Brand | Empire |
|---|---|
| Model | DVCT30CBN95 Insert |
| Type | Direct Vent Gas Insert |
Performance
| Max / Min BTU (NG) | 30,000 / 8,500 BTU/h |
|---|---|
| Max / Min BTU (LP) | 28,500 / 10,000 BTU/h |
| Fuel Options | Natural Gas or Propane |
| Ignition / Controls | Electronic ignition with multifunction remote (thermostat, flame, blower, light) |
Installation & Venting
| Venting | Direct vent, 5″ × 8″ coaxial |
|---|---|
| Minimum Fireplace Opening | ~19½″ width × ~31¼″ height × ~18″ depth (per spec)† |
| Insert Depth / Profile | ~17⅝″ depth inside opening† |
| Glass Viewing Area | ~25.5″ width × ~?″ height† |
Dimensions & Weight
| Dimensions (W×H×D) | ~30⅔″ W × ~19″ H × ~17⅝″ D |
|---|---|
| Weight | ~98 lb |
Documents (PDF): Homeowner’s & Installer Manual (PDF)
FAQs
Can the unit run flames without heat?
Yes — flame-only mode is supported independently of heat output.
What vent system is required?
This insert uses 5″ × 8″ direct-vent coaxial piping; no chimney needed.
What BTU does it deliver?
Up to ~30,000 BTU/h on natural gas; ~28,500 on propane.
Is blower included?
Yes — blower and accent lighting are included standard.
Are there fuel options?
Yes — models are available for natural gas or propane (factory or kit configured).
What is the warranty?
10-year limited on combustion chamber, lifetime on glass, 3 years on parts.
Warranty
Empire Rushmore DVCT30CBN95 — Limited warranty: 10-year on combustion chamber, lifetime on glass, 3 years on other parts.
Coverage
| Component | Term | Notes |
|---|---|---|
| Combustion Chamber / Firebox | 10 years | Structural defects under normal use. |
| Glass / Barrier Screen | Lifetime | Manufacturing defects only. |
| Other Parts (blower, electronics, logs, remote) | 3 years | Component-level warranty. |
Exclusions & Conditions
- Original purchaser with proof of purchase required.
- Improper installation, modifications, or misuse will void coverage.
- Labor, shipping, and installation costs are not covered unless otherwise specified.
Manuals & Installation
- Homeowner & Installer Manual: Download (PDF)
- TruFlame Brochure / Spec Sheet: Brochure (PDF)
From the Manual
“Maximum Input (Natural Gas): 30,000 BTU/h; Propane: 28,500 BTU/h.”
“Warranty: 10-year limited combustion chamber, lifetime on glass, 3-year parts.”
Pre-Install Checklist
- Confirm fireplace opening fits minimum requirements (19½″ W × 31¼″ H × 18″ D in many cases).
- Install approved 5″ × 8″ direct vent piping per manual.
- Provide proper gas supply lines and electrical connection for blower.
- Install barrier screen and verify clearance to combustibles per manual.
Compliance & Safety
Follow the manual and local building/gas codes exactly. Use qualified installers for gas and venting work. Keep vent paths clean and unobstructed.
Do not block air inlet/outlet. Use only the specified gas type. Inspect annually and maintain glass, logs, gaskets, and venting components.
